Moda Fabrics Illustrated Squares Quilt Pattern Summary

The Illustrated Squares Quilt by Moda Fabrics is a free downloadable PDF pattern that produces a finished quilt measuring 57" x 71¼". Rated as an intermediate quilting project, this design combines illustrated fabric panels with classic patchwork blocks to create a visually rich, structured quilt. The pattern is built around the Illustrations panel (11500 11) by Alli K Design, making it a fabric-forward project where the artwork takes center stage alongside traditional pieced blocks.

What Is Being Made

This pattern produces a single bed-sized or large lap quilt with a finished size of 57" x 71¼". The design is organized into multiple sections that incorporate four distinct illustrated panels alongside two types of patchwork blocks: Flying Geese units and Star blocks, as well as Plus Sign blocks. The layout balances the decorative illustrated panels with the geometric energy of the pieced elements, resulting in a quilt that feels both artistic and traditionally grounded.

Materials Used

Fabric Requirements

• Illustrations Panel (11500 11) by Alli K Design — the central fabric feature, divided into four panels used at specific trimmed sizes
• Off White Fabric (9900 200) — ¾ yard, used extensively throughout the Flying Geese units, Star blocks, and Plus Sign blocks
• Layer Cake (11500 LC) — 10" x 10" pre-cut squares, with 22 squares chosen to feature in the quilt and additional squares trimmed for specific sections
• Backing fabric — 4 yards required
• Batting — a 65" x 80" piece required

Tools and Notions

• Standard quilting rulers and rotary cutter for precise cutting
• Sewing machine suitable for patchwork piecing
• Marking tool for drawing diagonal lines on fabric squares

Pattern Sections and Panel Layout

The Illustrations panel is divided into four distinct panels, each trimmed to specific unfinished measurements before being incorporated into the quilt layout:

• Panel 1 — trimmed to 18" x 24¼" unfinished
• Panel 2 — trimmed to 18" x 28" unfinished
• Panel 3 — trimmed to 15½" x 24¼" unfinished
• Panel 4 — yields two pieces: (2) 10" x 10" squares and (1) 4½" x 4¼" piece, used in Section 2

The quilt is assembled in numbered sections, with fabric strips such as a 2" x 24¼" strip (Section 3) and a 2" x 29" strip (Section 2) used to join the panels and patchwork blocks together. A 1½" x 18" rectangle is also cut from the off-white fabric for use in Section 2.

Patchwork Blocks and Units

Flying Geese Units

The Flying Geese units finish at 2⅜" x 4¾". This is one of the most beloved classic quilt blocks, traditionally constructed by pairing a large rectangle with two smaller corner squares to create a triangular "goose" shape pointing in one direction. In this pattern, assembly begins by drawing a diagonal line on the wrong side of (48) 2⅞" off-white squares. These are then paired with 2⅞" x 5¼" rectangles cut from the Layer Cake squares, with the marked off-white squares placed right sides together at the corners of each rectangle. Sewing on the drawn diagonal line and trimming away the excess creates the signature angled triangle unit. Flying Geese units add strong directional movement and visual rhythm to the quilt layout.

Star Blocks
